8埠 Gigabit Easy Smart簡易智慧網管交換器

DGS-1100-08V2

  • Product Status (Ax v2.11WW): Live
  • 8埠10/100/1000 Mbps 自動速率偵測
  • 金屬外殼 無風扇靜音設計
  • 可置放桌面、支援壁掛安裝
  • Bandwidth Control ensures latency-sensitive traffic always gets the bandwidth it needs
  • Quality of Service further prioritizes latency-sensitive traffic, ensuring timely delivery
  • Segregate different types of traffic, such as surveillance or voice, with VLANs to heighten security
  • IGMP Snooping sends multicast traffic only where it needs to go, significantly cutting down network traffic
  • Innovative energy saving features are good for your budget, as well as the environment
Where to buy

產品規格

Interfaces
8 x GE
Switching Capacity
16 Gbps
Max. Packet Forwarding Rate
11.9 Mpps
Max Power Consumption
4.94 W
Dimensions
171 x 98 x 29 mm
Weight
0.34 kg
FAN
Fanless
Operating Temperature
0°C - 40°C (32°F - 104°F)
Storage Temperature
-40°C to 70°C ( -40°F to 158°F)
Operating Humidity
0% to 90% RH, non-condensing
Storage Humidity
0% to 95% RH, non-condensing
Power Supply Type
External

實際效能可能因設定、線纜、溫度、網路配置、介面、設備相容性、環境和現場條件以及其他類似因素而有所不同。有關功率、訊號或處理速度、訊號範圍或距離、資料加密、儲存容量、顯示特性或其他效能指標的說明均基於業界標準得出的最佳條件，僅供參考。規格如有變更，恕不另行通知。
