| Video & Audio Input |
| IP Video Input |
4ch |
| Audio Input |
N/A |
Video & Audio Output
|
| HDMI |
1 CH VGA output (1920×1080@60Hz 1280×1024@60Hz)1 CH HDMI output (2048 x 1080@ 30Hz, 1920×1080@60Hz, 1280×1024 @60Hz) (3840×2160@30Hz)
|
| VGA |
1 CH VGA output (1920×1080@60Hz 1280×1024@60Hz)1 CH HDMI output (2048 x 1080@ 30Hz, 1920×1080@60Hz, 1280×1024 @60Hz) (3840×2160@30Hz)
|
| Audio Output |
N/A |
| Recording |
| Compression |
H.265 /H.264 |
| Resolution |
4K /5MP /4MP / 3MP /1080P /720P /D1/CIF /QCIF
|
| Playback & Backup |
| Playback Mode |
Smart/ Normal/ Time Division/ Label/ Event/ Picture/ Log Playback
|
| Decoding Capability |
4×4K/25fps (Mainstream), 4×D1/25fps (Sub Stream) |
| Backup Mode |
USB Device/Network
|
| Advance Features |
| Smart Detection |
Line crossing, Area Intrusion, Fast moving, Unattached Object, Object Missing
|
| Smart Playback |
Line Crossing/Area Intrusion /Motion Detection
|
| Cloud Storage |
Support |
| Cloud Upgrade |
Support |
| Network |
| Incoming Bandwidth |
80 Mbps
|
| Outgoing Bandwidth |
80 Mbps |
| Ethernet |
1 RJ-45 10 /100 Mbps self-adaptive Ethernet interface |
| Network Compatibility |
HTTP, HTTPS, TCP/IP, IPv4, UPNP, RTSP, UDP, SMTP, NTP, DHCP, IP Filter, DDNS, FTP, P2P, ONVIF 2.6 |
| Smart Phone |
IOS (iPhone, iPad), Android (Phone, Pad) |
| Hard Disk |
| SATA |
1 SATA interface |
| Capacity |
Up to 10TB capacity for each HDD |
| Ethernet Interface |
| USB Interface |
Rear panel: 2 × USB 2.0
|
| General |
| Working Environment |
-10°C~+55°C / 10%~90%RH
|
| Power Supply |
DC 12V 2Amp |
| Dimension (W×D×H) |
92mmx192mmx42mm (LWH)
|
| Power Consumption |
<10W (without HDD) |
| Weight |
420 g |
