| Video & Audio Input | |
| IP Video Input | 32ch |
|---|---|
| Audio Input | 1-ch, RCA |
| Video & Audio Output | |
| HDMI | 1ch, resolution:4K(3840×2160)/30Hz,1920×1080/60Hz,1440×900/60Hz,1280 ×1024/60Hz, 1280×720/60Hz, 1024×768/60Hz |
| VGA | 1ch, resolution:1920×1080/60Hz,1440×900/60Hz,1280 ×1024/60Hz, 1280×720/60Hz,1024×768/60Hz |
| Audio Output | 1-ch, RCA |
| Recording | |
| Compression | H.265 /H.264 |
| Resolution | 8MP/5MP/4MP/3MP/1080P/720P/D1/CIF /QCIF |
| Playback & Backup | |
| Playback Mode | Smart/ Normal/ Time Division/ Label/ Event/ Picture/ Log Playback |
| Decoding Capability | 32×4K (Mainstream), 32*D1 (Sub Stream) |
| Backup Mode | USB Device/Network |
| Advance Features | |
| Smart Detection (Supported by camera) | Area Intrusion, Line crossing, Region Entrance /Region Exiting, Object Missing, Unattended Object, Human Detection, Vehicle Detection |
| Smart Playback | Line Crossing/Area Intrusion /Motion Detection |
| Cloud Storage | Support |
| Cloud Upgrade | Support |
| Network | |
| Incoming Bandwidth | 320 Mbps |
| Outgoing Bandwidth | 320 Mbps |
| Ethernet | 1 RJ-45 10 /100 Mbps self-adaptive Ethernet interface |
| Network Compatibility | HTTP, HTTPS, TCP/IP, IPv4, UPNP, RTSP, UDP, SMTP, NTP, DHCP, IP Filter, DDNS, FTP, P2P, ONVIF 2.6 |
| Smart Phone | IOS (iPhone, iPad), Android (Phone, Pad) |
| Hard Disk | |
| SATA | 4 SATA interface |
| Capacity | Up to 10TB capacity for each HDD |
| Ethernet Interface | |
| USB Interface | Front panel: 1 × USB 2.0 Rear panel: 2 × USB 2.0 |
| General | |
| Working Environment | -10°C~+55°C / 10%~90%RH |
| Power Supply | DC 12V 4Amp |
| Dimension (W×D×H) | 430mmx440mmx90mm (LWH) |
| Power Consumption | <10W (without HDD) |
| Weight | 2Kg approx |
| Certification |
CE, BIS |
